Diving into no-code automations with n8n

Table of Contents

1. Understanding n8n Data Flow
2. Workflow Management & Subflows
3. Error Handling & Resilience
4. Thinking in Workflows
5. Version Control Strategies

---

1. Understanding n8n Data Flow

📚 Official Docs

• Data structure
• Data transformation

Core Concepts

n8n processes data in “items”. Each item is an object with a json property:

// Single item
{
  json: {
    name: "John",
    email: "john@example.com"
  }
}

// Multiple items (array)
[
  { json: { name: "John", email: "john@example.com" } },
  { json: { name: "Jane", email: "jane@example.com" } }
]

Key Rules

1. Node Input: Each node receives an array of items
2. Node Output: Each node returns an array of items
3. Accessing Data: Use $json to access current item’s data

Practical Examples

Example 1: Simple Data Flow

[Manual Trigger] → [Code Node] → [HTTP Request]

Code Node:

// Access previous node's data
const userName = $json.name;
const userEmail = $json.email;

// Return data for next node
return [
  {
    json: {
      fullName: userName,
      contact: userEmail,
      timestamp: new Date().toISOString(),
    },
  },
];

Example 2: Processing Multiple Items

// When you have multiple items from previous node
const allItems = $input.all(); // Get all items as array

// Process each item
const processed = allItems.map((item) => ({
  json: {
    originalData: item.json,
    processed: true,
    processedAt: Date.now(),
  },
}));

return processed;

Example 3: Aggregating Data

// Combine multiple items into one
const allItems = $input.all();

return [
  {
    json: {
      items: allItems.map((item) => item.json),
      count: allItems.length,
      summary: "Combined " + allItems.length + " items",
    },
  },
];

🎯 Quick Reference

Expression	Purpose	Example
$json	Current item data	$json.name
$input.first()	First item	$input.first().json
$input.last()	Last item	$input.last().json
$input.all()	All items	$input.all()
$node["NodeName"]	Specific node data	$node["HTTP Request"].json

---

2. Workflow Management & Subflows

📚 Official Docs

• Execute Workflow node
• Sub-workflows

Pattern 1: Simple Subflow Call

Main Workflow:

[Trigger] → [Process Data] → [Execute Workflow: "Email Sender"] → [Log Result]

Subworkflow (“Email Sender”):

[When called by another workflow] → [Format Email] → [Send Email]

Configuration:

Execute Workflow Node:

• Source: Database
• Workflow: Select “Email Sender”
• Data automatically passes to subworkflow

In Subworkflow - Access Parent Data:

// Get data from parent workflow
const parentData = $input.first().json;

// Access specific fields
const articles = parentData.articles;
const metadata = parentData.metadata;

Pattern 2: Subflow with Return Value

Main Workflow:

// Before calling subworkflow
return [
  {
    json: {
      operation: "processData",
      data: myData,
      config: { timeout: 5000 },
    },
  },
];

Execute Workflow Node → Returns subworkflow output

After Execute Workflow:

// Access subworkflow result
const result = $json.result;
const status = $json.status;

console.log("Subworkflow returned:", result);

Pattern 3: Conditional Subflow Execution

[Process] → [IF Node] → True: [Execute Workflow: "Success Handler"]
                      → False: [Execute Workflow: "Error Handler"]

IF Node Condition:

{
  {
    $json.status === "success";
  }
}

Pattern 4: Multiple Subflows in Sequence

[Data] → [Execute: "Validate"] → [Execute: "Process"] → [Execute: "Notify"]

Each subworkflow receives output from previous one.

Pattern 5: Parallel Subflow Execution

                    → [Execute: "Process A"]
[Data] → [Split] →  → [Execute: "Process B"]  → [Merge] → [Combine Results]
                    → [Execute: "Process C"]

Use Split In Batches or Item Lists node.

🎯 Best Practices

✅ DO:

• Name subworkflows clearly: “Email - Send Digest”, “Data - Validate Input”
• Keep subworkflows focused (single responsibility)
• Use descriptive node names
• Add notes to complex subworkflows

❌ DON’T:

• Create circular dependencies (A calls B, B calls A)
• Pass huge datasets (>1MB) between workflows
• Nest subworkflows more than 3 levels deep

---

3. Error Handling & Resilience

📚 Official Docs

• Error handling
• Error Workflow

Strategy 1: Try-Catch Pattern with IF Node

[HTTP Request] → [IF: Check for Errors] → Success: [Continue]
                                         → Error: [Handle Error] → [Notify]

IF Node Condition:

{
  {
    $json.error === undefined && $json.statusCode === 200;
  }
}

Strategy 2: Built-in Error Handling

On any node, click the gear icon → Settings:

• Continue On Fail: ✅ (keeps workflow running)
• Retry On Fail: ✅
  • Max Tries: 3
  • Wait Between Tries: 1000ms (exponential backoff)

Example: Resilient HTTP Request

Settings:
- Continue On Fail: Yes
- Retry: 3 times
- Wait: 1000ms, 2000ms, 4000ms

Strategy 3: Error Workflow (Global Handler)

Create dedicated “Error Handler” workflow:

[Error Trigger] → [Parse Error] → [Log to Database] → [Send Alert]

Error Trigger Node:

// Access error details
const errorWorkflow = $json.workflow.name;
const errorNode = $json.node.name;
const errorMessage = $json.error.message;
const errorTime = $json.execution.startedAt;

return [
  {
    json: {
      workflow: errorWorkflow,
      node: errorNode,
      error: errorMessage,
      timestamp: errorTime,
      executionId: $json.execution.id,
    },
  },
];

Set as Global Error Workflow:

1. Go to Settings → Workflows
2. Set “Error Workflow” to your error handler

Strategy 4: Defensive Coding

// Always validate input
function processData(data) {
  // Validation
  if (!data || typeof data !== "object") {
    console.log("❌ Invalid data received");
    return { error: "Invalid input", success: false };
  }

  // Null checks
  const items = data.items || [];
  const config = data.config || {};

  // Try-catch for risky operations
  try {
    const result = riskyOperation(items);
    return { result, success: true };
  } catch (error) {
    console.log("❌ Error:", error.message);
    return { error: error.message, success: false };
  }
}

// Use it
const result = processData($json);

if (!result.success) {
  // Handle error path
  return [{ json: { status: "error", message: result.error } }];
}

// Continue with success path
return [{ json: { status: "success", data: result.result } }];

Strategy 5: Circuit Breaker Pattern

// Track failures
let failureCount = 0;
const MAX_FAILURES = 5;

// In your processing loop
try {
  const result = await externalService.call();
  failureCount = 0; // Reset on success
  return result;
} catch (error) {
  failureCount++;

  if (failureCount >= MAX_FAILURES) {
    console.log("🔴 Circuit breaker triggered - stopping workflow");
    throw new Error("Circuit breaker open: too many failures");
  }

  console.log(`⚠️ Failure ${failureCount}/${MAX_FAILURES}`);
  // Continue or retry
}

🎯 Resilience Checklist

• Enable “Continue On Fail” on external API calls
• Add retry logic with exponential backoff
• Validate all input data before processing
• Use try-catch blocks around risky operations
• Set up global error workflow for monitoring
• Add timeout limits on long-running operations
• Log errors with context (node name, input data)
• Send alerts for critical failures
• Test failure scenarios regularly

---

4. Thinking in Workflows

📚 Official Docs

• Workflow best practices
• Building workflows

The Workflow Mindset

Think in stages, not steps:

❌ Wrong Thinking: “I need to make an API call, then parse the response, then…”

✅ Right Thinking: “I need to: 1) Get Data → 2) Transform → 3) Act → 4) Report”

Pattern: Start Small, Grow Iteratively

Iteration 1: Basic Flow (Hardcoded)

[Manual Trigger] → [HTTP Request: Fixed URL] → [Show Result]

Iteration 2: Add Parameters

[Manual Trigger] → [Set Variables] → [HTTP Request: Use Variables] → [Show Result]

Iteration 3: Add Processing

[Trigger] → [Set Vars] → [HTTP Request] → [Filter Data] → [Transform] → [Show]

Iteration 4: Add Error Handling

[Trigger] → [Set] → [HTTP + Retry] → [IF: Success?] → Yes: [Process]
                                                      → No: [Log Error]

Iteration 5: Make Reusable

[Trigger] → [Validate Input] → [Execute Workflow: "API Handler"] → [Format Output]

Decomposition Strategy

Example: “Send Weekly Security Digest”

🔴 Bad Approach: One massive workflow with 30 nodes

🟢 Good Approach: Decompose into logical units

Main Workflow: "Security Digest Orchestrator"
├── Subworkflow: "RSS - Fetch Articles"
├── Subworkflow: "AI - Generate Summary"
├── Subworkflow: "Email - Send Digest"
└── Subworkflow: "Slack - Post Notification"

Each subworkflow is:

• Testable independently
• Reusable in other workflows
• Maintainable (easier to update)
• Understandable (single purpose)

Design Patterns

Pattern 1: Pipeline (Sequential Processing)

[Input] → [Validate] → [Transform] → [Enrich] → [Output]

Use When: Data flows linearly through transformations

Pattern 2: Branch (Conditional Logic)

[Input] → [Decision] → Path A: [Process A] → [Merge]
                     → Path B: [Process B] → [Merge]

Use When: Different handling based on conditions

Pattern 3: Map-Reduce (Batch Processing)

[Input] → [Split Items] → [Process Each] → [Aggregate] → [Output]

Use When: Processing lists of items

Pattern 4: Event-Driven (Trigger-Response)

[Webhook Trigger] → [Parse Event] → [Route by Type] → [Multiple Handlers]

Use When: Reacting to external events

Pattern 5: Scheduled Task (Time-Based)

[Cron Trigger] → [Fetch Data] → [Process] → [Report]

Use When: Regular automated tasks

Workflow Organization Framework

Use this naming convention:

[Category] - [Purpose] - [Version]

Examples:
- Data - Fetch RSS Articles - v2
- Email - Send Digest - v1
- Integration - Slack Notify - v3
- Utility - Validate JSON - v1

Folder Structure (in your mind/docs):

Workflows/
├── Core/ (main business workflows)
│   ├── Security Digest Orchestrator
│   └── Weekly Report Generator
├── Integrations/ (external services)
│   ├── RSS - Fetch Articles
│   ├── Slack - Post Message
│   └── Email - Send via Gmail
├── Utilities/ (reusable helpers)
│   ├── JSON - Validate
│   ├── Data - Clean HTML
│   └── Text - Truncate
└── Error Handlers/
    └── Global Error Handler

🎯 Development Workflow

1. Plan (5 min):

   • Write down inputs and outputs
   • Identify major stages
   • Sketch on paper

2. Prototype (15 min):

   • Build happy path only
   • Use hardcoded test data
   • Get something working

3. Test (10 min):

   • Run with real data
   • Check outputs
   • Note failures

4. Refine (20 min):

   • Add error handling
   • Parameterize hardcoded values
   • Improve logging

5. Extract (15 min):

   • Identify reusable parts
   • Create subworkflows
   • Clean up main flow

6. Document (5 min):

   • Add sticky notes
   • Name nodes clearly
   • Update workflow description

---

5. Version Control Strategies

📚 Official Docs

• n8n CLI
• Import/Export workflows

Strategy 1: Manual Export (Simplest)

Workflow:

1. Click “⋮” (three dots) on workflow
2. Select “Download”
3. Save as: workflow-name-v1.json

Folder Structure:

n8n-workflows/
├── production/
│   ├── security-digest-v2.json
│   └── email-sender-v1.json
├── staging/
│   └── security-digest-v3-beta.json
└── archive/
    ├── security-digest-v1.json
    └── email-sender-v0.json

Naming Convention:

[workflow-name]-v[major].[minor].json

Examples:
- security-digest-v1.0.json
- security-digest-v1.1.json (minor update)
- security-digest-v2.0.json (major rewrite)

Strategy 2: Git-Based Version Control (Recommended)

Setup:

# Create repository
mkdir n8n-workflows
cd n8n-workflows
git init

# Create structure
mkdir -p workflows/{production,staging,development}
mkdir -p subworkflows
mkdir -p docs

# Add .gitignore
cat > .gitignore << 'EOF'
# Sensitive data
*-credentials.json
.env

# Temporary files
*.tmp
*.bak
EOF

# Initial commit
git add .
git commit -m "Initial n8n workflows repository"

Workflow Process:

# 1. Start new feature
git checkout -b feature/add-slack-integration

# 2. Export workflow from n8n
# Go to n8n → Download workflow as JSON

# 3. Save to git
cp ~/Downloads/slack-integration.json workflows/development/
git add workflows/development/slack-integration.json
git commit -m "Add: Slack integration workflow

- Sends digest to #security channel
- Includes article count and top stories
- Handles rate limiting"

# 4. Test in development

# 5. Promote to staging
git checkout staging
git merge feature/add-slack-integration
cp workflows/development/slack-integration.json workflows/staging/
git commit -m "Promote: Slack integration to staging"

# 6. Test in staging

# 7. Deploy to production
git checkout main
git merge staging
cp workflows/staging/slack-integration.json workflows/production/
git tag -a v1.2.0 -m "Release: Add Slack integration"
git commit -m "Release: v1.2.0 - Slack integration"
git push origin main --tags

Strategy 3: Automated Backup Script

Create backup-workflows.sh:

#!/bin/bash

# Configuration
N8N_URL="http://localhost:5678"
N8N_API_KEY="your-api-key"
BACKUP_DIR="./backups/$(date +%Y-%m-%d)"

# Create backup directory
mkdir -p "$BACKUP_DIR"

# Export all workflows
echo "📦 Backing up n8n workflows..."

# Get list of workflows (requires n8n API)
curl -X GET "$N8N_URL/api/v1/workflows" \
  -H "X-N8N-API-KEY: $N8N_API_KEY" \
  | jq -r '.data[] | .id + "," + .name' \
  | while IFS=, read -r id name; do

    # Download workflow
    echo "  └─ Exporting: $name (ID: $id)"
    curl -X GET "$N8N_URL/api/v1/workflows/$id" \
      -H "X-N8N-API-KEY: $N8N_API_KEY" \
      > "$BACKUP_DIR/${name}-${id}.json"
  done

# Commit to git
cd "$BACKUP_DIR/.."
git add .
git commit -m "Auto-backup: $(date +%Y-%m-%d)"

echo "✅ Backup complete: $BACKUP_DIR"

Add to crontab:

# Daily backup at 2 AM
0 2 * * * /path/to/backup-workflows.sh

Strategy 4: Changelog and Documentation

Create CHANGELOG.md:

# Changelog

All notable changes to n8n workflows will be documented in this file.

## [2.0.0] - 2025-10-09

### Added

- Advanced filtering with AI-based scoring
- Support for multiple RSS categories
- Automatic retry on failed API calls

### Changed

- Improved email template with better formatting
- Reduced API costs by 40% with smarter filtering

### Fixed

- Bug where empty content caused crashes
- Category mapping not working for new feeds

### Removed

- Deprecated Fever API authentication (replaced with Basic Auth)

## [1.1.0] - 2025-10-01

### Added

- Email digest subworkflow
- Slack notification integration

### Fixed

- Timezone issues in scheduling

## [1.0.0] - 2025-09-25

### Added

- Initial release
- RSS feed fetching
- Basic email sending

Create README.md for each workflow:

# Security Digest Workflow

## Overview

Fetches security articles from RSS feeds, filters by relevance, and sends weekly email digest.

## Version

v2.0.0 (2025-10-09)

## Dependencies

- Subworkflow: "Email - Send Digest v1"
- Subworkflow: "RSS - Fetch Articles v2"
- External: CommaFeed RSS reader
- External: Gmail API

## Configuration

### Environment Variables

- `COMMAFEED_URL`: https://commafeed.lab.aminrj.com
- `COMMAFEED_USER`: amine
- `COMMAFEED_PASSWORD`: \*\*\*

### Schedule

- Runs: Every Monday at 9:00 AM
- Timezone: UTC

## Data Flow

1. Fetch categories and feeds from CommaFeed
2. Fetch articles (last 3 days)
3. Filter by relevance score (>3)
4. Select top 12 articles across categories
5. Generate email digest
6. Send via Gmail

## Testing

1. Pin test data from "Fetch Articles" node
2. Test "Advanced Filter" with pinned data
3. Verify output has 10-15 articles
4. Check email formatting in preview

## Rollback

If issues occur, revert to v1.1.0:

```bash
git checkout tags/v1.1.0
# Import workflow-v1.1.0.json to n8n
```

Maintenance

• Update feed URLs quarterly
• Review filter thresholds monthly
• Archive old versions after 6 months

### Strategy 5: Release Management

**Use semantic versioning:**

- **Major (1.0.0 → 2.0.0)**: Breaking changes, workflow restructure
- **Minor (1.0.0 → 1.1.0)**: New features, no breaking changes
- **Patch (1.0.0 → 1.0.1)**: Bug fixes, minor tweaks

**Release Checklist:**

```markdown
## Pre-Release Checklist

- [ ] All nodes have clear names
- [ ] Error handling on all API calls
- [ ] Sensitive data in environment variables (not hardcoded)
- [ ] Tested with production data
- [ ] Subworkflows are stable versions
- [ ] Documentation updated
- [ ] Changelog entry added
- [ ] Tagged in git
- [ ] Backup of previous version saved

## Post-Release Checklist

- [ ] Monitor first execution
- [ ] Check logs for errors
- [ ] Verify outputs match expected
- [ ] Update team documentation
- [ ] Schedule review in 1 week

🎯 Complete Git Workflow Example

# Initial setup
git init n8n-workflows
cd n8n-workflows

# Create structure
mkdir -p {workflows,subworkflows,docs,scripts}

# Track changes
git add .
git commit -m "Initial structure"

# Feature development
git checkout -b feature/improved-filtering
# ... make changes in n8n ...
# Export workflow
git add workflows/security-digest-v2.json
git commit -m "Improve: Article filtering algorithm

- Add AI-based relevance scoring
- Filter out duplicate articles
- Prioritize recent content"

# Tag release
git tag -a v2.0.0 -m "Release: Improved filtering"
git push origin v2.0.0

# Create changelog
echo "## [2.0.0] - $(date +%Y-%m-%d)" >> CHANGELOG.md
echo "### Improved" >> CHANGELOG.md
echo "- Article filtering with AI scoring" >> CHANGELOG.md
git add CHANGELOG.md
git commit -m "Update changelog for v2.0.0"

---

🎓 Learning Path: 30-Day Plan

Week 1: Foundations

• Day 1-2: Data flow and expressions
• Day 3-4: Build 3 simple workflows
• Day 5-7: Error handling practice

Week 2: Intermediate

• Day 8-10: Create first subworkflow
• Day 11-12: Refactor existing workflow
• Day 13-14: Set up git repository

Week 3: Advanced

• Day 15-17: Build complex multi-subworkflow system
• Day 18-19: Implement comprehensive error handling
• Day 20-21: Performance optimization

Week 4: Best Practices

• Day 22-24: Documentation and versioning
• Day 25-26: Monitoring and alerting
• Day 27-28: Code review with another workflow
• Day 29-30: Build something from scratch applying all concepts

---

📚 Additional Resources

Official Documentation

• n8n Documentation
• n8n Community Forum
• n8n GitHub

Video Tutorials

• n8n YouTube Channel
• Search: “n8n tutorials” for community content

Templates

• n8n Workflow Templates
• Study popular workflows for patterns

Community

• Discord Server
• Reddit r/n8n

---

🚀 Quick Start Checklist

Today, right now:

• Export your current workflow as JSON
• Create a git repository
• Commit your workflow with a meaningful message
• Add a README.md describing the workflow
• Identify one subworkflow you can extract
• Add error handling to one critical node
• Test a failure scenario

This week:

• Create your first subworkflow
• Set up automated backups
• Write documentation for main workflows
• Implement retry logic on API calls

This month:

• Refactor one complex workflow into modular parts
• Build a global error handler
• Create a workflow style guide for your team
• Implement monitoring and alerting

---

You’re now equipped to build professional, maintainable n8n workflows! Start small, iterate often, and always version your work. 🎉

---

Created: 2025-10-09 21:24 [[today-2025-10-09]]
